All Specifications
Display
Brightness (ANSI lumens)
4000
Resolution
1080P (1920x1080)
Native Aspect Ratio
16:9
Contrast Ratio (FOFO)
16,000:1
Display Color
30-bit (1.07 billion colors)
Light Source
Lamp
Light Source Life
a. Normal 4000 hrs, b. ECO 8000 hrs, c. SmartEco 8000 hrs, d. LampSave 15000 hrs
Optical
Throw Ratio
1.15~1.5
Zoom Ratio
1.3x
Lens
F/# = 2.59 - 2.87, f = 16.88 - 21.88 mm
Projection Offset (Full-Height)
115%
Keystone Adjustment
2D, (Auto) Vertical ± 30 degrees; Horizontal ± 20 degrees
Picture Modes
3D, Bright, Presentation, sRGB, User 1, User 2
Compatibility
Input Lag
33.4ms (1080p@60Hz) *downscaling to 480p
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
Horizontal Frequency
15K~102KHz
I/O Interface
PC in (D-sub 15pin)
PC in-1 (shared with component video)
Monitor out (D-sub 15pin)
(x1)
HDMI in
(x2), HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4/MHL)
LAN (RJ45)
(x1)
USB Type A
(x2), USB Type A-1 (2.0/Power Supply1.0A/Reader), USB Type A-2 (2.0/Power Supply1.0A/Wireless Dongle)
USB Type Mini B
(x1), USB Type Mini B-1(service/Page up&down)
RS232 in (DB-9pin)
(x1)
Audio
Speaker
10W
Audio in (3.5mm Mini Jack)
(x1)
Audio out (3.5mm Mini Jack)
(x1)
Environment
Operating Temperature
0~40℃
Power Supply
AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V)
320W
Stand-by Power Consumption
<0.5W
Network Stand-by Power Consumption
<2W
Acoustic Noise (Typ./Eco.)(dB)
33/29
Accessories
Wireless USB dongle
(Optional), WDRT8192
Carry Bag
Yes,QS1;(Optional)
Remote Control w/ Battery
RCE013
Power Cord (by region)
x1 (1.8M)
VGA(D-sub 15pin) Cable
(Standard), 1 (1.5m)
User Manual CD
1 (24L)
3D Glasses
(Optional), DGD5
Quick Start Guide
(x1) 18L
Warranty Card (by region)
Yes
Lens cover
Yes
Dimension & Weight
Dimensions (WxHxD) (mm)
296x120x221
Net Weight (kg)
2.5
Projection System
Projection System
DLP
Optical
Throw Ratio
1.15~1.5
Zoom Ratio
1.3X
Lens Control
Manual Zoom and Focus
Keystone Correction
2D keystone, Vertical ± 30 & Horizontal ± 20 degrees, Auto Vertical keystone
Projection Size
30"~300"
Projection Offset**
105%±2.5% (Full-Height)
Display
Projection System
DLP Single 0.65" Full HD
DMD type
DC3 DMD chip
Resolution
1920 x 1080 pixels, 16:9
Brightness
4,000 Lumens
Display Color
1.07 Billion Colors
Aspect Ratio
Native 16:9 (5 aspect ratio selectable)
Light Source
Lamp (240W)
Contrast Ratio
16,000:1
Light Source life*
4000/8000/8000/15000hrs
(Normal/Eco/SmartEco/Lampsave Mode)
(Normal/Eco/SmartEco/Lampsave Mode)
Audio
Built-in Speaker
10W x1
Feature
Security
Kensington Lock, Security Bar
Feature
2D Keystone, Auto Vertical keystone, Corner Fit, USB Reader,LAN Control, AMX/ PJ Link/Crestron/Extron IPL Compatible. MDA Compatibility LAN Display, Optional Wireless Display, Split Screen, Support Meeting/Classroom collaboration via QCast Software.(Conference Control)
Connectivity
I/O Port
HDMI-1 x1
HDMI-2/MHL x1
PC (D-sub 15pin) x1
Monitor out (D-sub 15pin,Female) x1
Audio in(mini jack) x1
Audio out (mini jack) x1
LAN Port(RJ45 for Network ) x1
RS232 In (D-sub 9pin, male) x1
USB TypeA (for USB reader) x1
USB TypeA (for Wireless Dongle) x1
USB (Type mini B) x1
IR Receiver(Front+Top) x2
HDMI-2/MHL x1
PC (D-sub 15pin) x1
Monitor out (D-sub 15pin,Female) x1
Audio in(mini jack) x1
Audio out (mini jack) x1
LAN Port(RJ45 for Network ) x1
RS232 In (D-sub 9pin, male) x1
USB TypeA (for USB reader) x1
USB TypeA (for Wireless Dongle) x1
USB (Type mini B) x1
IR Receiver(Front+Top) x2
Compatibility
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200)
Horizontal Frequency
15K - 102KHz
Vertical Scan Rate
23 - 120Hz
HDTV Compatibility
480i, 480p, 576i, 567p, 720p, 1080i, 1080p
Video Compatibility
NTSC, PAL, SECAM
Power
Power Comsumption(Max/Normal/Eco)
Max 355W. Normal 320W. Eco 240W.
Standby Power Comsumption
Normal < 0.5Watts. Network < 2W.
Dimension and Weight
Product Dimensions (WxHxD)
296x 120 x 221 mm
Product Weight
2.5kg
Operation Condition
Operating Temperature
0o ~ 40oC
Noise Level
33/29 Dba
Accessories
Accessories (Standard)
Power Cord (by region)
Remote Control (RCE013)
AAA Batteryx2
VGA cable
Warranty Card (by region)
QSG (4J.JGR01.001)
User Manual CD (5B.JGR01.001)
Lens Cover
Remote Control (RCE013)
AAA Batteryx2
VGA cable
Warranty Card (by region)
QSG (4J.JGR01.001)
User Manual CD (5B.JGR01.001)
Lens Cover
Accessories (Optional)
Spare Lamp Kit ( P/N: 5J.JGT05.001)
3D Glasses (5J.J9H25.002)
Wireless Dongle: WDRT8192 USB Dongle( 5J.J3F28.X01)
Wireless Dongle: QCast Mirror (5A.JH328.10X)
Wireless Dongle: QCast (5J.JCK28.X01)
Ceiling mount
3D Glasses (5J.J9H25.002)
Wireless Dongle: WDRT8192 USB Dongle( 5J.J3F28.X01)
Wireless Dongle: QCast Mirror (5A.JH328.10X)
Wireless Dongle: QCast (5J.JCK28.X01)
Ceiling mount
OSD
On Screen Display Language
Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/Thai/TraditionalChinese/Vietnamese /Farsi (30 Languages)
InstaShow Host
Power Supply
100 ~ 240V AC
